Panasonic vertical inserter RL132

PCB dimensions (mm): L 508 x W 381
Max.speed: 0.14 s/component
PCB exchange time: about 2 s to about 4 s (Room temperature 20 °C)
Insertion direction: 360°direction by 1°increment

Panasonic vertical inserter RL132

Specifications:


The RL132 combines functionality and speed with an insertion rate up to 25,700cph (.14s/component), a board processing sizes up to 650 x 381mm, a 33% reduction in PCB transfer time, up to 18% reduction in electrical and air consumption per insertion and an improved parts lifespan for a very low cost of ownership.

This through-hole machine features a 4-pitch span and is configurable with 40 or 80 components inputs. Meanwhile, its dual split carriage enables machine function at exchange mode and parts replenishment during production. The RL132 was designed for a non-stop productivity.

The Lead V cut method enables the RL132 to insert radial lead components at a speed of 0.14s/component. Either a 2-pitch (2.5mm/5.0mm), 3-pitch (2.5mm/5.0mm/7.5mm) or 4-pitch (2.5mm/5.0mm/7.5mm/10.0mm) option can be selected.

The fixed feeder unit method and an out-of-component detection function allow ongoing component replenishment and long-term runs. PCB of 650mm x 381mm can be processed.

Identical control panels are setup at the front side of the RL132 so that operability can be significantly improved. (Standard specification)

Up to 200 types of programs can be stored. Data can be input to and output from high-capacity SD memory cards.

NC data of our conventional equipment (RH series) can be used by the RL132.

Setup support functions that display the component layout of the component supply unit on the screen are provided.

Maintenance support functions that display information of regular maintenance time and operation content are provided.

Model ID

Panasonic vertical inserter RL132

Model No.

NM-EJR5A

NM-EJR6A

PCB dimensions (mm)

L 50 x W 50 to L 508 x W 381

Max.speed

0.14 s/component

No.of component inputs

40

80 (Connection mode), 40 + 40 (Exchange mode)

Applicable components

Pitch 2.5/5.0 mm (standard), 7.5 mm and 10 mm (option),
Resistor, Electrolytic capacitor, Ceramic capacitor, LED, Transistor, Filter, Resistor network

PCB exchange time

about 2 s to about 4 s (Room temperature 20 °C)

Insertion direction

360°direction by 1°increment

Electric source *1

3-phase AC 200 V, 3.5 kVA

Pneumatic source

0.5 MPa, 80 L/min (A.N.R.)

Dimensions (mm)

W 2 104 x D 2 183 x H 1 575 *2

W 3 200 x D 2 417 x H 1 575 *2

Mass *3

1 750 kg

2 350 kg

*1:Compatible with 3-phase 220 / 380 / 400 / 420 / 480 V

*2:Excluding signal tower

*3:Only for main body

* Values such as maximum speed may vary depending on operating conditions.

* Please refer to the “Specification” booklet for details.
